Description
Key Features
Quick View Energy Dashboard
- Eliminate the need for tangled cords and numerous screens with the sleek Renogy ONE M1. Equipped with a 4″ high-definition touch display, effortlessly oversee and command all compatible Renogy products throughout your household from a single screen.
Control All Your Connected Devices
- Take control of your energy consumption with RENOGY ONE M1. The panel relays allow for convenient switching of up to 3 DC appliances through easy-to-use panel switches or the DC Home app. Create personalized smart scenes to suit your lifestyle, like an “Evening” mode that illuminates your home or a “Sleep” mode that powers off appliances for added convenience.
Remote Energy Monitoring
- Stay connected even when you’re off the grid with Wi-Fi connectivity for real-time energy data monitoring, right at your fingertips through the DC Home app. Keep track of battery status, charge controllers, and other connected energy devices with ease.
*Gain access to 200 days worth of power generation data at a single touch. Explore your system’s performance history with ease and efficiency.
-
Package Includes
RENOGY ONE M1
1 x
Package Others
1 x
Specification
| Specifications | |
|---|---|
| Power Supply: | Rated Power 3.5W ● Power Port: 8V DC-16V DC ● Type-C Port: 5V DC |
| Load: ≤30V DC, 5A Max | Power Consumption: < 2.5W (standby) |
| Ports: | ● USB Type-C (5V DC) ● RJ45 (CAN & RS485) ● 2-pin 2.54 mm pluggable terminal block (12V DC) |
| Wireless Communication | ● Wi-Fi (IEEE 802.11b/g/n 2.4 GHz) ● Bluetooth 2.1/4.2 and Bluetooth LE ● Zigbee (IEEE 802.15.4) |
| Zigbee: IEEE 802.15.4 | Protocols: RV-C/Modbus/Zigbee 3.0 |
| Touch Screen: 4 inches (480 x 480p) White backlight with adjustable brightness |
Dimension: 181.8 x 86.8 x 42.2 mm (7.16 x 3.42 x 1.66 in) |
| Installation: Flush mounting | Weight: 286 g/0.83 lbs |
| Color: Black | Casing Material: PC+ABS V0 |
| Applicable Place: Indoor | Operating Altitude: Less than 2000 m above sea level |
| Operating Temperature: -20℃~50℃ (-4℉~122℉) | Operating Humidity: 0%~95%RH |
Warranty Information
| Product Warranty |
2 Years |
