Introducing Renogy ONE Core
Unboxing, Testing and Review
Renogy ONE Core Install & Review
Renogy Solar Monitor & Rv Leveling
Discover the Power of Renogy ONE Core
Renogy ONE Core
Install in a small Coachman Freedom Express 259FKDS Travel Trailer
Energy efficiency at your fingertips
Renogy ONE Core is a must-have for off-grid enthusiasts, aiding in cost reduction and sustainable living through precise monitoring of energy production and utilization.
Distance is not a problem
Efficiently monitor energy in different scenarios with Renogy ONE Core, an all-in-one system featuring a 4” touch screen.
One Command Center for Your Renogy Devices
Need leveling for more comfort?
The Renogy ONE Core helps you achieve optimal stability by adjusting your RV’s position, ensuring a comfortable and safe experience.
Built-in 6-axis leveling sensor
Accurately and precisely detects alterations in orientation and rotational motion with high responsiveness.
Real-time RV leveling status
Effortlessly receive precise real-time updates on your vehicle’s stability through the ONE Core Panel and DC Home App.
Make it a smart home
The Renogy ONE Core functions as both an energy system monitor and a smart home hub, facilitating connections with other smart home appliances such as door entry alerts and climate sensors. This provides increased convenience and security through home automation.
Peace of mind with 24/7 security
Monitor your RV for unexpected motions to stay alert and informed of any suspicious activity.
Effortless installation
Step 1
Complete a hole using a 55mm diameter punch and get all components of the device stand.
Step 2
With an embedded horizontal bubble, it’s easy to achieve the horizontality of the device and avoid repeated leveling.
Step 3
Rotate, click clack, it’s done.
Installation on Table
Step 1
Pull out the holder layer of the box.
Step 2
Raise up the support layer.
Step 3
Push back the holder layer and place One Core on it.Renogy ONE M1 vs Renogy ONE Core
Specification
|
ELECTRICAL DATA |
|
|---|---|
| Operating Voltage | 8-60 VDC (5 VDC for USB Type-C) |
| Power Consumption at 12V | Operating, WiFi On, 100% illumination: 3.2 W Operating, WiFi On, 50% illumination: 2.4 W Operating, WiFi On, 0% illumination: 1.9 W Off, logger still active: 1.5 W |
| Communication | Wi-Fi (IEEE 802.11b/g/n 2.4 GHz) Bluetooth LE and Bluetooth Mesh Zigbee 3.0 (IEEE 802.15.4) RS-485 |
| Touch Screen | 4 inches (480 x 480p) |
| Leveling Range and Accuracy | ±89°, 0.1° |
| GENERAL DATA | |
| Model | RSHGWSN-W02W-G1 |
| Operating Temperature | -4℉ to 158℉ (-20℃ to 70℃) |
| Operating Humidity | 0% to 95% RH |
| Operating Altitude | Less than 5000m above sea level |
| Installation | Flush mount or place on a table |
| Dimensions | 4.17 x 4.17 x 1.05 in (106 x 106 x 26.6 mm) |
| Weight | 0.28 lb (128g) |
| Certification | CE, FCC, RoHS, TSCA, BQB, IC-ID |
| Warranty | 2 years |
